PM865K02CPU module parameters are available worldwide

The PM865K02 is a high-performance CPU module. Its main parameters are as follows:
Processor:
Equipped with an industrial-grade Cortex-A8 720MHz embedded processor, it has powerful processing power and can quickly execute control logic and algorithms to meet the needs of complex industrial automation systems.
Memory:
Equipped with 512MB DDR2 RAM, it provides enough temporary storage space for system operation and data processing.
With 1GB Flash, it can be used to store programs, data and operating system, etc., to ensure the stable operation of the system and reliable storage of data.
Communication interface:
It has two 1000M Ethernet interfaces and supports IEEE1588 protocol, which can realize high-speed and stable data transmission and ensure the real-time and reliability of the system.
It provides 8 RS232/RS485 interfaces to facilitate communication with various serial devices and is suitable for different industrial communication scenarios.
It has two high-speed USB2.0 interfaces, which can connect USB devices, such as U disk, mouse, keyboard, etc., to facilitate data transmission and device operation.
There are also two industrial CAN2.0A/B bus interfaces that support CAN bus communication and data interaction with other CAN devices, which are suitable for industrial automation control.
Display and support:
Support standard VGA display, convenient for users to carry out real-time monitoring and operation, can intuitively display the system’s operating status and data information.
Support SD memory card, users can expand storage space according to needs, convenient data storage and backup.
Input/Output and simulation functions:
Provide 8 to 24 DIO (digital input and output) interfaces to connect a variety of digital signal equipment to meet the acquisition and control needs of digital signals in industrial automation systems.
Equipped with 8-channel 12-bit ADC (analog-to-digital converter) and 4-channel 16-bit DAC (digital-to-analog converter), it can achieve high-precision analog signal acquisition and output, which is suitable for industrial applications with high requirements for analog signal processing.
Other features:
Built-in real-time clock (RTC) and buzzer, providing time synchronization and alarm functions, convenient for users to manage the system time and alarm in abnormal circumstances.
The built-in temperature sensor can monitor the temperature status of the module in real time to ensure that the module works within the normal temperature range, which improves the stability and reliability of the system.
Supports hardware encryption to ensure the security of data transmission and prevent data from being illegally stolen or tampered with.
Operating system and environment adaptability:
Linux2.6 operating system is preinstalled, and supports Linux, Android, WinCE6.0 and other operating systems, providing users with flexible operating system choices.
It is suitable for wide industrial temperature environment from -40 ℃ to 80℃, has strong environmental adaptability, and can work stably in harsh industrial environment
