Honeywell 05701-A-0302 channel control card PDF available from stock

The Honeywell 05701-A-0302 is a single channel control card from Honeywell.
Its main functional features include:
Process monitoring: The ability to monitor various parameters in production or industrial processes in real time, such as temperature, pressure, flow, etc., to ensure that these parameters operate within a predetermined range.
Precise control: Through advanced control algorithms, the precise control of the equipment is achieved, thus ensuring the stability and efficiency of the production process.
Fault diagnosis and prevention: With fault diagnosis, potential problems can be detected and reported in a timely manner to help operators prevent or resolve faults and reduce downtime.
Integration and communication: Seamless integration with other automation and control devices and data exchange with other systems via standard communication protocols.
This control card is used in a wide range of fields, such as industrial automation, instrumentation, data acquisition, and gas alarm. In industrial automation, it can receive and process a variety of input signals, such as analog signals (such as voltage or current) or digital signals (such as switching state or digital sensor signals), and then perform a variety of logical and algorithmic operations to achieve precise manipulation of actuators, valves, motors or other control devices. In addition, it also has the function of catalyzing a1, a2, a3 gas alarms, and is equipped with a four-part LCD display, including analog display, digital display, information display and icon part for displaying various information.
Its specific technical specifications are as follows:
Display: Analog display is 25 segments, digital display is four characters, information display is four characters, the icon part is used for boot/card selection.
Led: a1, a2, a3 gas alarm function, as well as failure and suppression display.
Button: There is an alarm reset/card selection button.
Alarm set point resolution: 1% FS D steps.
Power consumption: 3.75W for catalysis (typical value, including catalytic sensor), 3.25W for 4-20mA (typical value).
DC power supply: 18V to 32V DC.
Electron drift: less than 2%/6 months.
Dimensions (L x W x H) : 17cm x 2.5cm x 11.2cm.
Weight: 0.165 kg, shipping weight is 1.5 kg.
