EPRO PR9376/20CS speed sensor

EPRO PR9376/20CS Speed Sensor is a high-performance speed sensor, the following is about its detailed information and parameters summary:

Model and Brand:
Model: EPRO PR9376/20CS
Brand: EPRO (Germany)
Application field:
The sensor is ideal for contactless velocity measurement in ferromagnetic machines and can be used for a wide range of industrial and laboratory applications.
Technical features:
High resolution: Output waveform even at low speeds, ideal for measuring very high and very low rotation speeds.
Rugged: Robust construction, enclosed in a stainless steel housing, ensures stable operation in harsh industrial environments.
Fast electronics and steep pulse slopes: Ensure accuracy and reliability of measurement results.
Differential sensor design: Using the differential sensor principle, the difference of Hall voltage is processed digitally through DSP (digital signal processor), so as to determine the output signal.
Long cable: Equipped with 5 meters long armored cable to meet a variety of installation needs.
Technical parameters:
Measuring range: 0… 20kHz
Measurement gap: ≤1.5mm
Sensor power supply: 8… 31.2 Vdc
Temperature range:
Operating temperature: -35℃~+80℃
Storage temperature: -40℃~+95℃
Cable length: 5 meters armored cable
Dimensions: Φ14×155mm
Operating voltage: 10-16V
Other parameters: center frequency 40.0±1.0KHz, sound pressure 105dB min, sensitivity -68dB min, electrostatic capacity 2000Pf±20%, etc.
Coordination system:
The sensor can be used with the RMS700 or MMS6000 system speed measurement module produced by epro, Germany, to measure speed, forward and reverse rotation, slow down and zero speed.
Functional application:
It can not only be used to measure rotation speed, but also to detect rotation direction, slide, static detection and other supervisory tasks.
Can be used as a proximity switch, for example for counting, generating alerts, etc.
