EPRO PR9376/000-011 vibrating sensor

The EPRO PR9376/000-011 vibration sensor is a device with high performance and reliability, mainly used to measure and monitor the speed of rotating objects such as shafts, gears, etc. The following are the details and parameters of the sensor:

1. Basic information
Brand: EPRO
Model: PR9376/000-011
Type: Vibration sensor (In fact, the PR9376 series is mainly a speed sensor, but can also be used for vibration monitoring related to speed)
2. Main technical parameters
Measurement principle: Differential magnetic field sensor
Trigger mode: non-contact mechanical trigger body
Trigger material: soft magnet or steel
Measuring range: 0… 20kHz (speed frequency range)
Measurement gap: ≤1.5mm (maximum allowable gap between sensor and measurement object)
Sensor power supply: 8… 31.2Vdc (operating voltage range)
Temperature range: -30℃… +100℃ (working ambient temperature range)
Cable length: optional 3 or 5 meters (armored cable)
Dimensions: Φ14×155mm (diameter and length)
3. Main features
High resolution: Output a clear waveform even at low speeds to ensure measurement accuracy.
Robust construction: Suitable for a variety of industrial environments, with good durability and reliability.
Non-contact measurement: No direct contact with the object to be measured, reducing wear and interference.
Wide temperature range: can work in a wide temperature range.
4. Application field
Mechanical equipment monitoring: used to monitor the speed and vibration of various rotating equipment, such as motors, pumps, fans, gear boxes, etc.
Turbine safety monitoring system TSI: As part of the TSI system, it is used to monitor the unit’s speed, zero speed, axial displacement, shaft eccentricity and other parameters.
5. Supply and price
Specific availability and pricing information may vary by region and sales channel, it is recommended to contact EPRO or its authorized distributor directly for inquiries.
6. Precautions
When installing and using sensors, follow the safety regulations to ensure the correct installation and stable operation of the sensors.
The sensor is checked and maintained regularly to ensure its long-term stability and reliability.
Sum up
The EPRO PR9376/000-011 vibration sensor is a powerful and stable speed and vibration monitoring device, which is widely used in various industrial fields. Its high resolution, robust construction and non-contact measurement make it ideal for mechanical equipment monitoring and steam turbine safety monitoring systems.
