EPRO PR9376/000-001 vibrating sensor

EPRO PR9376/000-001 speed sensor parameters and characteristics
Basic information:
Brand: EPRO
Model: PR9376/000-001
Main technical parameters:
Measuring range: 0… 20kHz (speed frequency range)
Measurement gap: ≤1.5mm (maximum allowable gap between sensor and measured object)
Sensor power supply: 8… 31.2Vdc (operating voltage range)
Temperature range: -30℃… +100℃ (working ambient temperature range)
Cable length: optional 3 or 5 meters (armored cable)
Dimensions: Φ14×155mm (diameter and length)
Functions and Applications:
Speed measurement: Used with the speed measurement gear plate to accurately measure the speed of the shaft.
Indirect vibration monitoring: although the PR9376/000-001 is not a specialized vibration sensor, the fluctuation of speed can indirectly reflect the vibration of the equipment, so as to be used for the condition monitoring and fault diagnosis of the equipment.
Other features:
High resolution: Output a clear waveform even at low speeds to ensure measurement accuracy.
Non-contact measurement: No direct contact with the object to be measured, reducing wear and interference.
Matters needing attention
When installing and using sensors, ensure that the relevant safe operating procedures are followed.
The sensor is checked and maintained regularly to ensure its long-term stable performance.
Sum up
EPRO PR9376/000-001 speed sensor with its high precision, high resolution and non-contact measurement characteristics, widely used in industrial applications to monitor the speed of equipment, thereby indirectly reflecting the vibration of equipment. It is a powerful, stable performance of industrial measuring equipment.
