EPRO PR9351 Thermal expansion sensor

The EPRO PR9351 is a thermal expansion sensor shield that works primarily with EPRO’s inductive displacement sensors such as the PR9350 series. The following are details and features of the EPRO PR9351 thermal expansion sensor shield:

Basic information
Brand: EPRO
Model: PR9351
Type: Thermal expansion sensor shield
Technical specification
Applicable sensors: PR9350/02 and PR9350/04 inductive displacement sensors
Size: 90×33×243mm (W×H×L)
Allowable travel: 100mm
Travel space required: 355mm
Weight (gross/net) : 3.0/2.0kg
Protection function: Provides protection for the sensor to ensure its stable operation in various industrial environments
peculiarity
Protection: PR9351 shield can effectively protect the sensor from the external environment (such as oil, water, dust, etc.), improve the service life and reliability of the sensor.
Compatibility: The shield is designed for EPRO PR9350 series inductive displacement sensors, ensuring a perfect match and collaboration with the sensor.
Convenient installation: The shield design is reasonable, easy to install, can be quickly installed on the sensor, reduce installation time and cost.
Application field
The EPRO PR9351 thermal expansion sensor cover is widely used in industrial fields requiring accurate measurement and monitoring of thermal expansion, such as steam turbines, generators, compressors and other equipment. By combining with PR9350 series inductive displacement sensor, real-time monitoring and early warning of thermal expansion of equipment can be realized to ensure the normal operation and safety of equipment.

Sum up
The EPRO PR9351 is a high-performance, highly reliable thermal expansion sensor shield for the EPRO PR9350 series of inductive displacement sensors. Its excellent protection and compatibility make the shield ideal for thermal expansion measurements in industrial applications.
