EPRO 177230-01-01-05 vibrating sensor

EPRO 177230-01-01-05 Vibration sensor is a powerful monitoring device, the following is a detailed description of it:

Basic information
Brand: EPRO (or possibly Bently Nevada, as Bently Nevada’s products are mentioned in some articles related to this model)
Model: 177230-01-01-05
Type: Vibration sensor
Technical specification
Measuring range: 0-25.4mm/s (This means that the maximum vibration speed that the sensor can measure is 25.4mm/s)
Corresponding output current: 4–20mA (sensor output current signal range, often used for analog signal transmission)
Response frequency: 10HZ-1000HZ (sensor can respond to the frequency range)
Velocity direction: From the bottom to the sensor (forward) (indicates the direction of vibration velocity measured by the sensor)
Ambient temperature: -30℃–+70℃ (ambient temperature range within which the sensor can work normally)
Power supply voltage: 12V- 36V (voltage range that provides power to the sensor)
Shell material: stainless steel (the material of the sensor shell, to ensure its durability)
Weight: 109 g (weight information of sensor)
Mounting thread: M101.5 thread or M81.25 or M6*1 (depending on the site) (describes the mounting method and thread specifications of the sensor)
Piezoelectric material: PZT-5 (Type of piezoelectric material used inside the sensor)
Output mode: two-wire system (indicates the signal type of sensor output)
Application field
EPRO 177230-01-01-05 Vibration sensors are widely used in various fields that need to monitor the vibration of mechanical equipment, such as ports, heating, gas, water supply, sewage treatment, metallurgy, etc. It can help users to understand and grasp the operating status of the equipment in time to ensure the safe and stable operation of the equipment.
