ABB PP865 touch screen specifications are available worldwide

In stock
  • Screen Size and Resolution: 15-inch TFT color touchscreen with a resolution of 1024 x 768 pixels, enabling graphical and textual display as well as touch operation.
  • Serial Ports:
    • RS422/RS485: 25-pin D-sub contact, chassis-mounted female connector with standard locking screws 4-40UNC.
    • RS232C: 9-pin D-sub contact, external thread, with standard locking screws 4-40UNC.
Image 1
Image 2
WhatsApp 图标
Phone: +86 13368533614
Email: 3127402866@qq.com
Here are the English parameter specifications of the ABB PP865 product:



  • Screen Size and Resolution: 15-inch TFT color touchscreen with a resolution of 1024 x 768 pixels, enabling graphical and textual display as well as touch operation.
  • Serial Ports:
    • RS422/RS485: 25-pin D-sub contact, chassis-mounted female connector with standard locking screws 4-40UNC.
    • RS232C: 9-pin D-sub contact, external thread, with standard locking screws 4-40UNC.
  • Ethernet: Shielded RJ45 interface.
  • USB Interface: Host type A (USB1.1), with a maximum output current of 500mA, and device type B (USB1.1).
  • CF Slot: Compact Flash, Type I and II flash memory, with a capacity of 12MB for applications (including fonts).
  • Real-time Clock Error: Due to the influence of ambient temperature and power supply, the real-time clock error is 20ppm voltage, and the total maximum error is 1 minute/month at 25°C, with a temperature coefficient of -0.034 ± 0.006ppm/°C².
  • Mode Switches: There are four mode switches (DIP switches) on the back of the operation panel. All mode switches must be in the off position during use, and they should not be touched unless operated by qualified personnel.
  • Protection Level: The front panel seal is IP66, and the rear panel seal is IP20.
  • Dimensions: The front panel width × height × depth is 398 × 304 × 6 mm, and the installation depth is 60 mm (160 mm when including the gap front panel seal).
  • Weight: 3.7 kilograms.
