product details
Extended Product Type: CP511
Product number: 1SBP260173R1001
ABB model name: CP511
Catalog description: CP511 control panel, requires CP500 software
Detailed description: Control panel with 8 programmable and 10 function keys, LCD graphic and text display screen 5.2“
ABB model name: CP511
Ambient air temperature: operation 0+ 50 ° C
Storage -20+ 70 ° C
Battery type: portable
CN8:84716070
Communication: Driver dependent
Communication interface: Ethernet with IFC ETTP
Communication speed: 9.6… 57.6 kBd
Origin: Sweden (SE)
CSA Certificate: NRAG7.E224886
Customs tariff number: 84716070
Data sheet, technical information: 1SBC159001M6501
Declaration of Conformity – CE: 1SBD240564C1000
Protection level: IP65
Display type: STN image and text
Environmental information: 1SBD240173E1000
Fieldbus interface type: Modbus RTUAC500_ Modbus ASCII Profibus DP Slave (optional) Modbus TCP_ IP Other (Contact Us)
Frame size: unclear
Fuse size: 5 x 20_ MMTx
Fuse type: 800 meters
Total weight: 1.6 kilograms
GSD file for PROFIBUS communication: CP500_ IFC-PBDP.gsd
Instructions and Manual: 1SBC159002M0202
Invoice description: CP511 control panel, requires CP500 software
Lloyd’s certificate: LRS_ 0620036
Customization: No
Memory size: 400 KB
Memory size User data: 400 KB
User program memory size: 400 KB
Memory type user data: 400 KB non volatile RAM
Memory type user program: 400 KB flash EPROM
Minimum order quantity: 1 piece
Mounted on DIN rails: No
Installation type: front face
Characters per line: Chapter 740
Number of displayed rows: 48
Number of function keys: 18
Number of LEDs: 16
Operation mode: No
Order multiple: 1 piece
Power consumption (@ P cons): 10.8 V · A
Power supply: 24V DC
Product depth: 75mm
Main type of product: CP511
Product Name: Control Panel
Product net depth/length: 69mm
Product net height: 198 millimeters
Net weight of product: 1.5 kilograms
Product net width: 211 millimeters
Product category: PLC-CP500
Fieldbus: with IFC PBDP
Programming software: CP500 software
Quote only: No
Real-time clock: Yes
Release type: V1.02
Screen color: black and white LCD with backlight
Screen resolution: 64 pixels
Screen size: 5.2 inches
Screen type: STN graphics and text
Security: 8 user level password protection
Sales Unit of measurement: pieces
Serial port 1 type: PR, MODBUS, ASCII, other
Serial port 2 type: PR, MODBUS, ASCII, other
Service life: 50000 hours
Short Introduction: Control Panel 8+10 Function Keys LCD Graphics&
Short circuit protection device: gG type integrated fuse
Software Function: Alarm Management Recipe Management Trends
Inventory in (warehouse): Menden, Germany
Power supply voltage: 20 30 VDC
UL certificate: NRAG.E224886
USB Port 1 Type: No
USB Port 2 Type: No
Height of visible area: 33.9mm
Visual area length: 127.2 mm
WEEE B2C/B2B: Between Enterprises
Category of abandoned electronic and electrical equipment: 5. Small equipment (external dimensions not exceeding 50 centimeters)
