product details
Extended product type: CP502
Product number: 1SBP260171R1001
ABB model name: CP502
Catalog description: CP502 control panel, requires CP500 software
Detailed description: Control panel with 3 programmable and 8 function keys, LCD text display with 2 lines and 20 characters
ABB model name: CP502
Ambient air temperature: operation 0+ 50 ° C
Storage -20+ 70 ° C
Battery type: portable
Character height: 5.55 millimeters
CN8:84716070
Communication: Driver dependent
Communication interface: No
Communication speed: 9.6… 57.6 kBd
Origin: Sweden (SE)
CSA Certificate: NRAG7.E224886
Customs tariff number: 84716070
Data sheet, technical information: 1SBC159001M6501
Declaration of Conformity – CE: 1SBD240563C1000
Protection level: IP65
Display type: STN text
Environmental information: 1SBD240171E1000
Fieldbus interface type: Modbus RTUAC500_ ModbusASCII Other (Contact Us)
Frame size: unclear
Fuse size: 5 x 20_ MMTx
Fuse type: 800 meters
Total weight: 0.5 kg
GSD file for PROFIBUS communication: No
Instructions and Manual: 1SBC159002M0202
Invoice description: CP502 control panel, requires CP500 software
Lloyd’s certificate: LRS_ 0620036
Customization: No
Memory size: 64 KB
Memory size User data: 64 KB
User program memory size: 64 KB
Memory type user data: 64 KB non volatile RAM
Memory type user program: 64 KB flash EPROM
Minimum order quantity: 1 piece
Mounted on DIN rails: No
Installation type: front face
Characters per line: 20
Display rows: 2
Number of function keys: 11
Number of LEDs: 0
Operation mode: No
Order multiple: 1 piece
Power consumption (@ P cons): 3.6 V · A
Power supply: 24V DC
Product depth: 46.5mm
Main type of product: CP502
Product Name: Control Panel
Product net depth/length: 29 millimeters
Product net height: 100mm
Net weight of product: 0.37 kilograms
Product net width: 142mm
Product category: PLC-CP500
Fieldbus: No
Programming software: CP500 software
Quote only: No
Real-time clock: Yes
Release type: V1.02
Screen color: LCD screen with backlight
Screen size: 2.8 inches
Screen type: STN text
Security: 8 user level password protection
Sales Unit of measurement: pieces
Serial port 1 type: PR, MODBUS, ASCII, other
Serial port 2 type: PR, MODBUS, ASCII, other
Service life: 50000 hours
Short Introduction: Control Panel 3+8 Function Keys LCD Text Display
Short circuit protection device: gG type integrated fuse
Software function: Menu management
Inventory in (warehouse): Menden, Germany
Wycliffe, Ohio, USA
New Berlin, Wisconsin, USA
Power supply voltage: 20 30 VDC
UL certificate: NRAG.E224886
USB Port 1 Type: No
USB Port 2 Type: No
WEEE B2C/B2B: Between Enterprises
Category of abandoned electronic and electrical equipment: 5. Small equipment (external dimensions not exceeding 50 centimeters)
