product details
Extended product type: CD522
Product number: 1SAP260300R0001
ABB model name: CD522
International Product Code: 4016779671668
Catalog description: Functional modules. 2 encoder inputs. 2 pulse width modulated outputs. 2 DI 24VDC. 8 configurable DI/DO 24VDC (CD522)
Detailed description: CD522: S500 functional module. 2 encoder inputs. 2 pulse width modulated outputs. 2 DI 24VDC. 8 configurable DI/DO 24VDC.
Origin: Germany (DE)
Finland (FI)
CN8:85389091
Invoice description: functional module. 2 encoder inputs. 2 pulse width modulated outputs. 2 DI 24VDC. 8 configurable DI/DO 24VDC (CD522)
Customization: No
Minimum order quantity: 1 piece
Order multiple: 1 piece
Sales Unit of measurement: pieces
aspect
Net weight of product: 0.124 kilograms
Product net depth/length: 62 millimeters
Product net height: 76mm
Product net width: 67.5 millimeters
Total weight: 0.151 kg
Package level 1 depth/length: 84 mm
Packaging layer 1 height: 72 millimeters
Package level 1 width: 71 mm
Package Level 1 Unit: 1 box
Technical
Function: 2 encoder inputs. 2 pulse width modulated outputs. 2 DI 24VDC. 8 configurable DI/DO 24VDC
Digitally configurable I/O quantity: 8
Output voltage (U output): 24V DC
Output current: 2A
Protection level: IP20
Power supply voltage: 24 VDC
Ambient air temperature: operation 0+ 60 ° C
Storage -40+ 70 ° C
Additional Information
Main product type: CD522
Product Name: Distributed Automation I/O
classification
Electronic course: 24/27/2005
EPLAN directory tree: Electrical Engineering/PLC/Comprehensive
ETIM 8: EC001422- PLC Function/Technical Module
United Nations Social Security Commission: 32151705
Environmental
SCIP: 2084bd69-e6ed-40c9-ac25-8cac44e581ca Germany (DE)
WEEE B2C/B2B: Between Enterprises
Category of abandoned electronic and electrical equipment: 5. Small equipment (external dimensions not exceeding 50 centimeters)
