product details
Extended product type: CI511-ETHCAT
Product number: 1SAP220900R0001
ABB model name: CI511-ETHCAT
International Product Code: 4016779664820
Directory description: Interface module. EtherCAT slave station. 4 AI: U, I, RTD. 2 AO: U, I. 8 DI: 24VDC. 8 DO: 24VDC 0.5A. Cam switch function (CI511-ETHCAT)
Detailed description: CI511-ETHCAT: S500 interface module. EtherCAT slave station. 4 AI: U, I, RTD. 2 AO: U, I. 8 DI: 24VDC. 8 DO: 24VDC 0.5A. Cam switch function. Can expand up to 10 I/O modules.
Origin: Germany (DE)
Finland (FI)
CN8:85389091
Invoice description: Interface module. EtherCAT slave station. 4 AI: U, I, RTD. 2 AO: U, I. 8 DI: 24VDC. 8 DO: 24VDC 0.5A. Cam switch function (CI511-ETHCAT)
Customization: No
Minimum order quantity: 1 piece
Order multiple: 1 piece
Sales Unit of measurement: pieces
aspect
Net weight of product: 0.138 kilograms
Product net depth/length: 62 millimeters
Product net height: 76mm
Product net width: 67.5 millimeters
Total weight: 0.162 kg
Package level 1 depth/length: 84 mm
Packaging layer 1 height: 72 millimeters
Package level 1 width: 71 mm
Package Level 1 Unit: 1 box
Technical
Function: EtherCAT slave station. 4 AI: U, I, RTD. 2 AO: U, I. 8 DI: 24VDC. 8 DO: 24VDC 0.5A. Cam switch function
Number of hardware interfaces: Industrial Ethernet 2
Other 0
Parallel 0
RS-232 0
RS-422 0
RS-485 0
Serial TTY 0
USB 0
Wireless 0
Analog input: 4
Analog output: 2
Number of digital inputs: 8
Number of digital outputs: 8
Number of digitally configurable I/O: 0
Input voltage type: DC
Input voltage (U in): 24 VDC
Input current: 5 mA
Delay time（ τ）： 0.1… 32 milliseconds
Output: Transistor
Output voltage type: DC
Output current: 0.5A
Maximum output voltage: 20.4… 28.8 volts
Protection level: IP20
Power supply voltage: 20.4… 28.8 V DC
Additional Information
Main type of product: CI511
Product Name: Distributed Automation I/O
classification
Electronic course: 27-24-26-07
EPLAN directory tree: Electrical Engineering/PLC/Comprehensive
ETIM 8: EC001604- Fieldbus, eccentric. Peripheral – Communication module
United Nations Social Security Commission: 32151705
Environmental
SCIP: 8070cf6d-0c4e-45d4-a548-e34b150e30d2 Germany (DE)
WEEE B2C/B2B: Between Enterprises
Category of abandoned electronic and electrical equipment: 5. Small equipment (external dimensions not exceeding 50 centimeters)
