product details
Extended product type: PM591-ARCNET-R01xx
Product number: 1SAP150100R0160
ABB model name: PM591-ARCNET
International Product Code: 4016779656009
Catalog Description: PM591-ARCNET: AC500, Program Logic Controller
Detailed description: PM591-ARCNET: AC500, Programmable logic controller 4MB, 24VDC, ARCNET, 2xRS232/485, FBP SD card slot, LCD display
ABB model name: PM591-ARCNET
ABS certificate: 1SAA960002-0106
Ambient air temperature: operation 0+ 60 ° C
Storage -40+ 70 ° C
Arc net: 1
BV certificate: 1SAA960003-0204
CN8:85389091
Communication: Serial and ARCNET interfaces for communication and programming
Communication interface: serial port/FBP/ARCNET
Communication speed: Logic 1000 instructions speed=0.05 0.05 0.05
Speed of 1000 instructions per word=0.05 0.05 0.05
Floating-point speed of 1000 instructions=0.5 0.5
Origin: Germany (DE)
CS31 Bus: 1
CSA Certificate: 1SAA960000-1712
CUL certificate: 1SAA960000-1712
CULus certificate: 1SAA960000-1712
Customs tariff number: 85389091
Data sheet, technical information: 2CDC125002B0207
Declaration of Conformity – CE: 1SAD938504-0161
Declaration of Conformity – C-Tick: 1SAA960000-3302
Declaration of Conformity – KCC: 1SAA960001-4801
Protection level: IP20
Display type: LCD display screen
Det Norske Veritas Certificate: 1SAA960002-0306
International Product Code: 4016779656009
Environmental information: 1SAA960007-2406
Fieldbus interface type: ARCNET
Frame size: unclear
GL Certificate: 1SAA960004-0409
GOST certificate: 1SAA962000-2703
Total weight: 0.22 kilograms
Input/output options: CPU with local IO – on I/O bus
Instructions and manual: 2CDC125080M0202
Invoice description: PM591-ARCNET: AC500, program logic controller
Lloyd’s certificate: 1SAA960002-0506
Customization: No
Maximum number of analog I/O: Local maximum 160 AI, 160 AO, 10 expansion modules
Maximum number of digital I/O: Local maximum 320 DI, 240 DO/DC, 10 expansion modules
Maximum allowable working height: 2000 meters
Memory size User data: 3584 KB
User program memory size: 4096 KB
Memory type user data: Flash EPROM
Memory type user program: flash EPROM, non volatile RAM, SD card
Minimum order quantity: 1 piece
Installed on DIN rail: TH35-15 (35 x 15 mm mounting rail) meets. Compliant with IEC 60715
Installation position: Horizontal and vertical adjustable derating
Display rows: 1
Number of function keys: 8
Number of LEDs: 3
Order multiple: 1 piece
Power supply: 24V DC
Primary voltage: 24 VDC
Product depth: 72 millimeters
Main product type: PM591
Product Name: Distributed Automation PLC
Product net depth/length: 62 millimeters
Product net height: 76mm
Net weight of product: 0.16 kilograms
Product net width: 67.5 millimeters
Product category: PLC-AC500
Programming software: PS501-PROG Control Builder Plus
Quote only: No
Real-time clock: Yes
Replace product ID (new): 1SAP150100R0260
Italian Classification Society Certificate: 1SAA960003-0807
RMRS certificate: 1SAA960001-0706
Hazardous Substance Restriction Directive Information: 1SAA960005-4410
RoHS status: No declaration required
Secondary current: 0.2A
Sales Unit of measurement: pieces
Serial port 1 type: RS232/RS485 configurable, programmable, Modbus master or slave, ASCII, CS31 master
Serial port 2 type: RS232/RS485 configurable, programmable, Modbus master or slave, ASCII
Short introduction: PM591-ARCNET: AC500, program logic controller
Inventory in (warehouse): Menden, Germany
Menden, Germany
New Berlin, Wisconsin, USA
Singapore, Singapore
Beijing, China
Singapore, Singapore
Australia, Australia
Power supply voltage: 24 VDC
UL certificate: 1SAA960000-1612
WEEE B2C/B2B: Between Enterprises
Category of abandoned electronic and electrical equipment: 5. Small equipment (external dimensions not exceeding 50 centimeters)
