product details
Extended product type: EC581-ARCNET-R01xx
Product number: 1SAP140500R3160
ABB model name: EC581-ARCNET
International Product Code: 4016779653770
Catalog Description: EC581-ARCNET: AC500, Program Logic Controller
Detailed description: EC581-ARCNET: AC500, Programmable logic controller 256kB, 24VDC, ARCNET, 2xRS232/485, FBP SD card slot, LCD display
ABB model name: EC581-ARCNET
Ambient air temperature: operation 0+ 60 ° C
Storage -40+ 70 ° C
Arc net: 1
BV certificate: 1SAA960000-0201
CN8:85389091
Communication: Serial and ARCNET interfaces for communication and programming
Communication interface: serial port/FBP/ARCNET
Communication speed: Logic 1000 instructions speed=0.05 0.05 0.05 ms
Speed of 1000 instructions per word=0.05 0.06 ms
Floating-point 1000 instructions speed=0.5 0.50 ms
Origin: Germany (DE)
CS31 Bus: 1
CSA Certificate: 1SAA960000-1705
CUL certificate: 1SAA960000-1705
Customs tariff number: 85389091
Data sheet, technical information: 2CDC125002B0206
Declaration of Conformity – CE: 1SAD938502-0161
Protection level: IP20
Display type: LCD display screen
Det Norske Veritas Certificate: 1SAA960002-0302
International Product Code: 4016779653770
Electronic course: 24/27/2007
Environmental information: 1SAA960007-2402
Fieldbus interface type: ARCNET
Frame size: unclear
GL Certificate: 1SAA960004-0404
Total weight: 0.22 kilograms
Input/output options: CPU with local IO – on I/O bus
Instructions and Manual: 2CDC125017M0202
Invoice Description: EC581-ARCNET: AC500, Program Logic Controller
Lloyd’s certificate: 1SAA960002-0503
Customization: No
Maximum number of analog I/O: 160AI, 160AO local, maximum 10 expansion modules
Maximum number of digital I/O: 320DI, 240DO/DC local, maximum 10 expansion modules
Maximum allowable working height: 2000 meters
Memory size User data: 288 KB
User program memory size: 256 KB
Memory type user data: Flash EPROM
Memory type user program: flash EPROM, non volatile RAM, SD card
Minimum order quantity: 1 piece
Installed on DIN rail: TH35-15 (35 x 15 mm mounting rail) meets. Compliant with IEC 60715
Installation position: Horizontal and vertical adjustable derating
Display rows: 1
Number of function keys: 8
Number of LEDs: 3
Order multiple: 1 piece
Power supply: 24V DC
Primary voltage: 24 VDC
Product depth: 72 millimeters
Main product type: EC581
Product Name: Distributed Automation PLC
Product net depth/length: 62 millimeters
Product net height: 76mm
Net weight of product: 0.16 kilograms
Product net width: 67.5 millimeters
Product category: PLC-AC500
Programming software: PS501-PROG Control Builder Plus
Quote only: No
Real-time clock: Yes
Replace product ID (new): 1SAP140500R3260
Italian Classification Society Certificate: 1SAA960003-0803
Hazardous Substance Restriction Directive Information: 1SAA960004-4406
Secondary current: 0.2A
Sales Unit of measurement: pieces
Serial port 1 type: RS232/RS485 configurable, programmable, Modbus master or slave, ASCII, CS31 master
Serial port 2 type: RS232/RS485 configurable, programmable, Modbus master or slave, ASCII
Short Introduction: EC581-ARCNET: AC500, Program Logic Controller
Inventory in (warehouse): Menden, Germany
Power supply voltage: 24 VDC
UL certificate: 1SAA960000-1606
United Nations Social Security Commission: 32151705
WEEE B2C/B2B: Between Enterprises
Category of abandoned electronic and electrical equipment: 5. Small equipment (external dimensions not exceeding 50 centimeters)
