product details
Extended product type: PM571-ETH-R01xx
Product number: 1SAP130100R0170
ABB model name: PM571-ETH
International Product Code: 4016779649315
Catalog description: PM571-ETH: AC500, program logic control 64kB
Detailed description: PM571-ETH: AC500, program log controller 64kB 24VDC, Ethernet, 2xRS232/485, FBP SD card slot, LCD display screen
ABB model name: PM571-ETH
ABS certificate: 1SAA960002-0106
Ambient air temperature: operation 0+ 60 ° C
Storage -40+ 70 ° C
BV certificate: 1SAA960003-0204
CN8:85389091
Communication: Serial and Ethernet interfaces for communication and programming
Communication interface: serial port/FBP/Ethernet
Communication speed: Logic 1000 instructions speed=0.05 0.06 ms
Speed of 1000 instructions per word=0.05 0.09 ms
Floating-point 1000 instructions speed=0.5 0.70 ms
Core Credit: 0.00
Origin: Germany (DE)
CS31 Bus: 1
CSA Certificate: 1SAA960000-1712
CUL certificate: 1SAA960000-1712
CULus certificate: 1SAA960000-1712
Customs tariff number: 85389091
Data sheet, technical information: 2CDC125002B0207
Declaration of Conformity – CE: 1SAD938504-0161
Declaration of Conformity – C-Tick: 1SAA960000-3302
Declaration of Conformity – KCC: 1SAA960001-4801
Protection level: IP20
Display type: LCD display screen
Det Norske Veritas Certificate: 1SAA960002-0306
International Product Code: 4016779649315
Electronic course: 24/27/2007
Environmental information: 1SAA960007-2406
Fieldbus interface type: Ethernet TCP/IP
Frame size: unclear
GL Certificate: 1SAA960004-0409
GOST certificate: 1SAA962000-2703
Total weight: 0.2 kg
Input/output options: CPU with local IO – on I/O bus
Instructions and manual: 2CDC125080M0202
Invoice description: PM571-ETH: AC500, program logic control 64kB
Lloyd’s certificate: 1SAA960002-0506
Customization: No
Maximum number of analog I/O: Local maximum 160 AI, 160 AO, 10 expansion modules
Maximum number of digital I/O: Local maximum 320 DI, 240 DO/DC, 10 expansion modules
Maximum allowable working height: 2000 meters
Memory size User data: 28 KB
User program memory size: 64 KB
Memory type user data: Flash EPROM
Memory type user program: flash EPROM, non volatile RAM, SD card
Minimum order quantity: 1 piece
Installed on DIN rail: TH35-15 (35 x 15 mm mounting rail) meets. Compliant with IEC 60715
Installation position: Horizontal and vertical adjustable derating
Display rows: 1
Number of function keys: 8
Number of LEDs: 3
Object classification code: K
Order multiple: 1 piece
Power supply: 24V DC
Primary voltage: 24 VDC
Product depth: 72 millimeters
Main type of product: PM571
Product Name: Distributed Automation PLC
Product net depth/length: 62 millimeters
Product net height: 76mm
Net weight of product: 0.15 kilograms
Product net width: 67.5 millimeters
Product category: PLC-AC500
Programming software: PS501-PROG Control Builder Plus
Quote only: No
Real-time clock: Yes
Replace product ID (new): 1SAP130100R0270
Italian Classification Society Certificate: 1SAA960003-0807
RMRS certificate: 1SAA960001-0706
Hazardous Substance Restriction Directive Information: 1SAA960005-4410
RoHS status: No declaration required
Secondary current: 0.2A
Sales Unit of measurement: pieces
Serial port 1 type: RS232/RS485 configurable, programmable, Modbus master or slave, ASCII, CS31 master
Serial port 2 type: RS232/RS485 configurable, programmable, Modbus master or slave, ASCII
Short introduction: PM571-ETH: AC500, program log controller 64kB
Inventory in (warehouse): Singapore, Singapore
Power supply voltage: 24 VDC
UL certificate: 1SAA960000-1612
United Nations Social Security Commission: 32151705
WEEE B2C/B2B: Between Enterprises
Category of abandoned electronic and electrical equipment: 5. Small equipment (external dimensions not exceeding 50 centimeters)
